CRF150R / CRF150RB Electric starter (2007-2026)

CRF150R / CRF150RB Electric starter (2007-2026)

Price range: $950.00 USD through $1,070.00 USD

EAN: N/A SKU: N/A Category:

Description

This kit fits the CRF150R and CRF150RB from 2007 to 2026. Original kickstarter remains functional.

You will be getting:

  • Complete starter unit, including all gears, bearings and electric motor
  • Full wiring harness with push button
  • Battery box
  • Battery (optional)

The complete kit with lithium battery will add 4.5 lb.

Tools required

  • 3/8 drive socket wrench
  • Socket wrench extension
  • 8mm socket
  • 10mm socket
  • 17mm socket
  • 5mm Allen drive bit (long tip)
  • 4mm Allen drive bit
  • 60-150 in-lb torque wrench
  • ½ drive 150 ft-lb torque wrench

Main steps installation

  1. Battery box and wiring harness installation.
  2. Main gear installation
  3. Starter housing installation
  4. Starter and battery connection
  5. Side panel and seat re-installation

PRESS THE BUTTON AND GO HAVE FUN !!

Warranty Items

All merchandise manufactured by Panthera Motorsports has a warranty against manufacturing defects for a period of one (1) year from the date of original shipping. (See details)

Additional information

Weight 10 lbs
Dimensions 11 × 11 × 10 in
Battery

Battery Not included, Battery Included
CRF150R ELECTRIC STARTER KIT (HON14-000) — exploded diagram

Click to expand

# Part Name Qty Price
01 HOUSING CRF150R E-STARTER HON14-M01 1 $500.00 USD
02 CAP, HOUSING CRF150R HON14-M01.2 1 $48.50 USD
03 BENDIX HON14-G01 1 $108.00 USD
04 MAIN GEAR, CRF150R HON14-G02 1 $85.00 USD
05 CROWN/GEAR CRF150R (ASSEMBLY) HON14-G03A 1 $118.00 USD
06 GASKET, HOUSING, CRF150R E-STARTER HON14-GA01 1 $10.25 USD
07 GASKET, CAP, CRF150R E-STARTER HON14-GA02 1 $9.25 USD
08 ELECTRIC MOTOR, CRF150R (12v,2b,ccw,13t) HON14-E02A 1 $109.00 USD
09 CRF150R BEARING INSTALLATION TOOL HON14-TL01 1 $4.00 USD
10 SQUARE NUT, CLIP CLUTCH CABLE HON14-F01 1 $2.35 USD
11 SPACER, LG 20mm HON14-M04 1 $3.00 USD
12 BEARING 19 PAN00-B19 3 $2.54 USD
13 BEARING 25 PAN00-B25 1 $11.25 USD
14 TOLERANCE RING PAN00-BU01 1 $5.00 USD
15 SHCS M6X25mm, SS PAN00-F46 5 $0.77 USD
16 SHCS M6X30mm, SS PAN00-F106 1 $0.95 USD
17 SHCS, M6x35mm, SS PAN00-F47 3 $0.77 USD
18 SHCS M6X20mm, SS PAN00-F83 2 $0.77 USD
19 BHCS M6X10mm, SS PAN00-F173 6 $0.95 USD
20 SHCS M4 X 20 SS PAN00-F195 3 $0.95 USD
21 SHCS M5 X 8 SS PAN00-F201 2 $0.95 USD
22 WASHER M6 STD (6.5x12x1.38) SS PAN00-F203 2 $0.25 USD
23 SHIM, 1x8x14mm, SPRING STEEL PAN00-F234 1 $1.95 USD
24 PLUG 1/16 NPT x 0.313", SS PAN00-F235 2 $1.95 USD
25 SHCS M6x8mm, Gr8.8 LOW PROFILE PAN00-F240 2 $1.95 USD
26 SEAL, STARTER HOUSING TO CRANKSHAFT HON14-S01 1 $7.25 USD
