YZ250 (2022-2026) – Electric starter kit

Price range: $1,160.00 USD through $1,475.00 USD

EAN: N/A SKU: N/A Category: Tags: , , , ,

Description

*Note that the charging version of YZ250 starter kit is no longer available.

This Yamaha YZ250 electric starter kit is available in charging and non-charging version:
– the charging version with it 90W charging system replace the stock stator and flywheel and will charge the battery in addition to allow accessories to be wired to the battery.
– the non-charging version will use the OEM flywheel and will start around 200 times before needing a charge (when using Antigravity 801 battery).

Recommended battery is the Antigravity SC-1 (4 cells)

The complete kit with lithium battery will add 5.7 lb

This kit includes the following:

  • Machined billet housing aluminum, anodized black
  • Electric motor
  • Main ring gear
  • Crown gear
  • Intermediate gear
  • General bearings
  • Bolting shaft
  • Gaskets and hardware
  • Battery box (battery not included)
  • Harness
  • Relay
  • Push button
  • Carbon fiber guard *optional
  • Stator with lighting current *charging version
  • Flywheel *charging version
  • Current rectifier *charging version

View YZ250 owner and install guide

Tools required

  • General mechanics tooling
  • Yamaha M27x1 flywheel puller
  • 4, 5 and 6mm allen drive bit
  • 60-150 in-lb torque wrench
  • ½ drive torque wrench

Main steps installation

  1. Battery box and wiring installation.
  2. Panthera stator installation (for starter kit with charging system).
  3. Flywheel and main gear installation.
  4. Starter housing installation.
  5. Starter and battery connection.
  6. Tank and seat re-install.

PRESS THE BUTTON AND GO HAVE FUN !!

Maintenance

It is recommended to flush the oil after the first ride to eliminate particles generated by the gears first meshing and break in. Taking cover off to remove all particles is recommended versus only using the drain plug.

On a normal basis, change the oil at the same time as transmission oil.

Warranty Items

All merchandise manufactured by Panthera Motorsports has a warranty against manufacturing defects for a period of one (1) year from the date of original shipping. (See details)

Benefits

Tired of kicking?! Boost your old YZ250 with our electric start (2nd generation).

Check out our Yamaha YZ250 Electric Start Installation video

Additional information

Weight 10 lbs
Dimensions 11 × 11 × 10 in
Charging system

No charging system, 90W DC Charging system
Carbon fiber guard

No carbon fiber guard, Carbon fiber guard
Battery

Battery included, Battery not included
YZ250-YZ250X ELECTRIC STARTER KIT (YAM01-000) — exploded diagram

Click to expand

# Part Name Qty Price
01 YZ250 Starter Housing YAM01-M01 1 $355.00 USD
02 YZ250 starter gear cap YAM01-M01.2 1 $57.00 USD
03 Bolting unit YAM01-M04 1 $28.00 USD
04 YZ250 flywheel heart replacement YAM01-M07 1 $100.00 USD
05 MAIN GEAR (ONEWAY GEAR) YAM01-G01 1 $135.00 USD
06 Crown gear 38/18 YAM01-G02A 1 $72.00 USD
07 Torque limiter gear YAM01-G03A 1 $115.00 USD
08 YZ250 starter housing gasket YAM01-GA01 1 $13.85 USD
09 GASKET, starter cap YAM01-GA02 1 $9.25 USD
10 Electric motor, standard (2b,ccw) YAM01-E02 1 $96.00 USD
11 BEARING 18 PAN00-B18 1 $10.77 USD
12 BEARING 19 PAN00-B19 4 $2.54 USD
13 BEARING 20 PAN00-B20 1 $15.23 USD
14 M8 COPPER CRUSH WASHER PAN00-F29 1 $2.00 USD
15 SHCS, M6x35mm, SS PAN00-F47 5 $0.77 USD
16 BHCS M8x12mm SS PAN00-F50 1 $0.77 USD
17 SHCS M6X20mm, SS PAN00-F83 2 $0.77 USD
18 SHCS M6X20mm, SS PAN00-F82 4 $0.77 USD
19 Countersunk SS rivet 5x10 PAN00-F104 6 $1.15 USD
20 1/16 NPT 90deg breather vent PAN00-F105 1 $3.00 USD
21 YZ 2003-21 - batt. box assembly- 8 cells (No regulator) YAM01-T01A 1 $290.00 USD
22 YZ 2003-21 - batt. box assembly- 4 cells (No regulator) YAM01-T02A 1 $235.00 USD
23 YZ 2022+ - batt. box assembly- 4 cells (No regulator) YAM01-T02A-22 1 $235.00 USD
24 YZ250 starter carbon fiber guard YAM01-M08 1 $200.00 USD
